Arrange impulse response plots into one figure per shock

Arranges a list of IRF panels, as returned by plotirf() or plot2irf(), into a grid with one figure per shock dimension and a common x-axis label. Optionally saves each figure as a PDF.

Usage

arrangeirf(
  myGraphs,
  E = 1,
  N,
  nRows = 1,
  xLab = "Horizon",
  title = NULL,
  file = NA,
  figScaleW = 3.5,
  figScaleH = 2.5
)

Arguments

myGraphs

List of ggplot objects of length E * N, ordered by shock (outer loop) and then by variable (inner loop), as returned by plotirf() and plot2irf().

E

Integer. Number of shock dimensions (one figure per shock). Defaults to 1

N

Integer. Number of variables (panels per figure).

nRows

Integer. Number of rows of panels in each figure. The number of columns is ceiling(N / nRows). Defaults to 1.

xLab

Character. Common x-axis label printed below the panels.

title

Character vector of length E (or 1, recycled) with a title printed above each figure, or NULL (default) for no title.

file

Character or NA. If not NA, file path stem; figure e is saved as paste0(file, "_", e, ".pdf"). If NA (default), nothing is saved.

figScaleW

Numeric. Width of one panel column in inches.

figScaleH

Numeric. Height of one panel row in inches. The saved figure has height 0.9 * nRows * figScaleH.

Value

Invisibly, a list of length E of arranged figures (gtable objects), which can be redrawn with grid::grid.draw(). Each figure is also drawn on the current graphics device as a side effect.

Examples

irf <- array(c(1, 0.5, 0.2, 0.1, 0, 0.3, 0.2, 0.1), dim = c(4, 2, 1))
dimnames(irf)[[1]] <- 0:3
se <- array(0.1, dim = dim(irf), dimnames = dimnames(irf))
g <- plotirf(irf, se, HTick = 1, Labels = c("Output", "Prices"))
figs <- arrangeirf(g, E = 1, N = 2, nRows = 1)


# \donttest{
# Save to PDF (file is written as <stem>_1.pdf)
stem <- file.path(tempdir(), "irf")
arrangeirf(g, E = 1, N = 2, nRows = 1, file = stem)

# }
